Continuously adjustable OConnor sinusoidal counterbalance and fluid drag that together give the ultra-smooth characteristic OConnor feel over the largest payload range.

OConnor does a good job of identifying what actually is going to work in the field and what we need and don’t need. I’ve used a lot of different fluid heads, but OConnor is just so far above and beyond the performance of every other fluid head in the market.
Description
OConnor introduces the 2575’s baby brother… the 2560.
Perfectly suited to the adaptable, a la carte configurations of accessorised digital cinematography. Cameras such as the Alexa in portable configuration or any lightweight digital cinema camera (from Sony, Canon, ARRI, AJA, JVC, Panasonic, Vision Research, RED) in ‘maxed out’ studio configuration.
OConnor Ultimate heads have been used on almost every Hollywood movie feature and episodic TV Drama since the early 1990’s and OConnor heads in general have been heavily utilised in the industry since 1949.
Model | 2560 |
Capacity | |
@ 4 in. (102 mm) @ 6 in. (152 mm) @ 8 in. (203 mm) |
83 lbs. (37.7 kg) 65 lbs. (29.5 kg) 53 lbs. (24.1 kg) |
Tilt | +/- 90 degrees tilt |
Height | 8 in. (20.3 cm) |
Width | 11.3 in. (28.7 cm) |
Depth | 7.5 in. (19.1 cm) |
Weight | 16.2 lb. (7.3 kg) |

ULTIMATE 2560 FLUID HEAD PACKAGE | C1260-0001 |
Package includes: | |
Ultimate 2560 Fluid Head | C1260-0002 |
Euro Style Quick Release | 2575-120 |
Pan handle | 2575-137 |
Pan handle extension | 2575-135 |
Mitchell base & tiedown | 08281 & C1234-1018 |
150mm Ball base & tiedown | 08414 & C1234-1017 |
ULTIMATE 2560 FLUID HEAD | C1260-0002 |
FRONT END HANDLE, SMALL ROSETTE | C1260-1010 |
